Product Overview

The CMP multistage centrifugal electric pump (hereinafter referred to as the pump) consists of three parts: an electric motor, a water pump, and a mechanical seal. The outer casing of this series of pumps is made of stainless steel, while the impeller and guide vanes are made of high-strength engineering plastic, offering strong corrosion resistance and durability. A double-end mechanical seal structure is used between the water pump and the electric motor, with a rotating water-retaining ring on the shaft serving as an auxiliary water-throwing and isolation mechanism. An O-ring is used for static sealing at the fixed stop seal.

Product Applications

This series of electric pumps features an attractive appearance, compact structure, easy installation, and convenient use. It is an ideal household pump that is highly efficient, energy-saving, safe, and environmentally friendly. It is widely used in farmland and garden irrigation, tap water pressurization, water tower supply, and well water lifting, among other applications.

Operating conditions

1. The conveying medium is clean water, with a temperature ≤40°C;

2. The pH value of the medium is between 6.5 and 8.5;

3. The ambient temperature is ≤45°C;

4. The volume percentage of solid impurities in the medium does not exceed 0.1%, and the particle size is not greater than 0.2mm;

5. The power supply is single-phase AC 220V/50Hz or three-phase AC 380V/50Hz, with a fluctuation range of ±10% of the rated value.
