Pump
• Stainless steel/Brass/PPO impeller
• Max.liquid temperature: +40 ℃
• Max.Suction: +9m
• Cast iron pump body and support
Motor
• Motor with copper winding
• Shaft: Stainless steel welded shaft/45# steel shaft
• Insulation Class:B or F
• Protection class: IPX4
• Max.Ambient temperature: +40℃
• Cooling: External ventilation
Pump Installation And Application
It can be used to transfer clean water or other liquid similar to water in physical and chemical properties. It is suitable for lifting water from the well, sprinkling irrigation in garden, pressure boosting of running water, and supporting equipment etc.
Performance Chart At N=2850rpm
MODEL | POWER | MAX.FLOW | MAX.HEAD | MAX.SUCT | INLET/OUTLET | GW | PACKING | |
kW | HP | |||||||
SSC-60 | 0.45 | 0.6 | 40 | 36 | 9 | 1"×1" | 13.0 | 440×200×230 |
SSC-80 | 0.6 | 0.8 | 50 | 38 | 9 | 1"×1" | 14.5 | 440×200×230 |
SSC-100 | 0.75 | 1 | 60 | 43 | 9 | 1"×1" | 15.5 | 440×200×230 |
SSC-110 | 1.1 | 1.5 | 60 | 55 | 9 | 1"×1" | 16.0 | 455×200×230 |
M/60 | 0.45 | 0.6 | 40 | 38 | 9 | 1"×1" | 13.0 | 440×200×230 |
M/70 | 0.6 | 0.8 | 50 | 40 | 9 | 1"×1" | 14.5 | 440×200×230 |
M/80 | 0.75 | 1 | 60 | 45 | 9 | 1"×1" | 15.5 | 440×200×230 |
M/100 | 1.1 | 1.5 | 60 | 55 | 9 | 1"×1" | 16.0 | 455×200×230 |
