Description
Permanent magnet frequency conversion pump, referred to multi-mode permanent magnet frequency conversion self-priming centrifugal pump, pump is mainly composed of permanent magnet motor, pump,mechanical seal, outer cover and frequency conversion controller, is a collection of power saving, constant pressure, bass as one of the intelligent household pump.
Application
Pump is widely used in household water, well water, tap water pressure, garden irrigation, vegetable greenhouses water supply. Especially suitable for insufficient water pressure water heater pipe, the full range of automatic protection, the number of fault code automatic display, pipeline leakage, water shortage indication.
Operating conditions
Liquid PH: 6-8.5
Liquid temperature: 0-40℃
Ambient humidity: max.85%(RH)
Liquid medium temperature: 0-60℃
(Under special circumstances, the temperature of the medium shall not exceed 90℃)
MODEL | POWER | ELECTRIC | FLOW | MAX FLOW | HEAD | MAX HEAD | OPERATING | SUCTION |
25QT-25BP | 0.9 | 6.5 | 5.0 | 8.0 | 25 | 30 | 1.5-2.4kgf/cm² | 5 |
32QT7-20BP | 1.1 | 7.3 | 7.0 | 9.5 | 20 | 30 | 1.5-2.4kgf/cm² | 5 |
YC200 | 0.2 | 2.2 | 1 | 3 | 20 | 30 | 4 | |
YC300 | 0.32 | 2.8 | 1.5 | 4.2 | 22 | 30 | 4 | |
YC600 | 0.6 | 5.0 | 3 | 6.3 | 30 | 52 | 4 | |
YC900 | 0.9 | 7.0 | 4 | 7.2 | 35 | 56 | 4 |
